Lens Mount Canon EF
Camera Format Full-Frame (1x Crop Factor)
Pixels Actual: 21.4 Megapixel
Effective: 20.1 Megapixel
Maximum Resolution 5472 x 3648
Aspect Ratio 3:2
Sensor Type CMOS
Sensor Size 36 x 24 mm
Image File Format JPEG, Raw, HEIF
Bit Depth 14-Bit
Image Stabilization Digital (Video Only)
Exposure Control
ISO Sensitivity Auto, 100 to 102400 (Extended: 50 to 819200)
Shutter Speed Mechanical Shutter
1/8000 to 30 Seconds
Bulb Mode
Metering Method Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation -5 to +5 EV (1/3, 1/2 EV Steps)
Metering Range 0 to 20 EV
White Balance Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Continuous Shooting Up to 20 fps at 20.1 MP for up to 1000 Frames (Raw)
Up to 16 fps at 20.1 MP for up to 1000 Frames (Raw)
Interval Recording Yes
Self-Timer 2/10-Second Delay
Mirror Lock-Up Yes
Video
Recording Modes Raw 12-Bit
5.5K (5472 x 2886) at 23.976p/24.00p/25p/29.97p/50p/59.94p [1800 to 2600 Mb/s]
MP4/H.265 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [170 to 1000 Mb/s]
UHD 4K (3840 x 2160) at 25p/29.97p/50p/59.94p [170 to 1000 Mb/s]
Full HD (1920 x 1080) at 25p/29.97p/50p/59.94p/100p/119.88p [18 to 470 Mb/s]
MP4/H.264 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [120 to 940 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/25p/29.97p/50p/59.94p [120 to 940 Mb/s]
Full HD (1920 x 1080) at 25p/29.97p/50p/59.94p/100p/119.88p [12 to 360 Mb/s]
External Recording Modes 4:2:2 10-Bit
DCI 4K (4096 x 2160) up to 59.94p
Recording Limit Up to 29 Minutes, 59 Seconds
Video Encoding NTSC/PAL
Audio Recording Built-In Microphone (Stereo)
External Microphone Input (Stereo)
Audio File Format AAC, Linear PCM (Stereo)
Focus
Focus Type Auto and Manual Focus
Focus Mode Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S)
Autofocus Points Phase Detection: 191 (155 Cross-Type)
Autofocus Sensitivity -4 to +18 EV
Viewfinder and Monitor
Viewfinder Type Optical (Pentaprism)
Viewfinder Eye Point 20 mm
Viewfinder Coverage 100%
Viewfinder Magnification Approx. 0.76x
Diopter Adjustment -3 to +1
Monitor Size 3.2″
Monitor Resolution 2,100,000 Dot
Monitor Type Fixed Touchscreen LCD
Flash
Built-In Flash No
Maximum Sync Speed 1/250 Second
Flash Compensation -3 to +3 EV (1/3 EV Steps)
Dedicated Flash System eTTL
External Flash Connection Hot Shoe, PC Terminal
Interface
Memory Card Slot Dual Slot: CFexpress Type B (CFexpress 1.0)
Connectivity USB Type-C (USB 3.1), HDMI C (Mini), Canon N3, 3.5mm Headphone, 3.5mm Microphone, PC Sync Socket, RJ45
Wireless Bluetooth
Wi-Fi
GPS Yes
Physical
Battery 1 x LP-E19 Rechargeable Lithium-Ion, 11.1 VDC, 2750 mAh (Approx. 2850 Shots)
Dimensions (W x H x D) 6.22 x 6.6 x 3.25″ / 158 x 167.6 x 82.6 mm
Weight 2.75 lb / 1250 g (Body Only)
3.17 lb / 1440 g (Body with Battery and Memory)
